MasterHandler

Up to 8,800 lbs.

Maximum control and maneuverability of all-swiveling loads

The MasterHandler range is specifically designed to deliver the controlled movement of loads weighing up to 8,800 lbs. that are fitted with all-swiveling castors. 

Featuring a unique design centered around delivering maximum control, the MasterHandler enables operators to easily steer and position heavy loads that ordinarily would be difficult to move in a controlled way. With adjustable support legs available to deliver a controlled fixed point, the MasterHandler can provide a turnkey solution to the movement of loads with all swiveling castors. 

The MasterHandler has a compact machine footprint and is ideal for use in confined areas, facilitating safe and precise movements where space is at a premium. The range uses an array of hydraulic coupling options to deliver consistent performance and guarantee load security. 

Safety  

Flashing safety light, warning horn, emergency stop and anti-crush button 
Speed control with optional two-speed selector switch 
Secure coupling for attachment to loads

Performance 

Designed to deliver complete control when moving loads with all-swivel castors 
A compact machine footprint provides a tight turning circle for space-restricted areas
Powerful and optimized hydraulics ensure a smooth and secure connection

Power  

Powerful AC motor optimizes both speed and power, enabling powerful movement of loads up to 8,800 lbs. 
Adaptable motor able to operate at slow and fast speeds and different acceleration rates 
High-performance AGM maintenance-free battery

Connection 

Secure coupling options to suit various cart designs 
Optimized couplings to deliver maximum performance through weight transfer 
Adjustable support legs deliver maximum steering control designed around your load 
Custom coupling designs

Explore the MasterHandler Range

With no operator license required, the MasterHandler range maximizes operational efficiency and reduces manual handling to remove the risk of injuries. With a compact design, the MasterHandler range guarantees the safe and controlled movement of large, heavy-wheeled loads in tight spaces.

Filters applied

44 Results

MH400+

Download technical information

Request a quote

Load capacity 8800 lbs
Maximum slope 7 °
Max distance per charge (standard battery) 5.7 miles
Charge time (external charger) 5.5h
Maximum push force 882 lbs
Maximum pull force 882 lbs
Standard IP rating IP44
Dimensions (w x l x h) 26 x 17.7 x 53.3 inch
Interchangeable battery No
Lithium battery No
Stainless steel Yes
ATEX Yes

Safety & Machine Options

The MasterHandler range comes with a wide variety of standard safety features. Additional options are available depending on your application requirements.

Safety
Connection

Safety

Two speed selector switch

Adjustable speed settings at your fingertips.

MasterHandler flashing light and bleeper

Safety light beacon

Maximize safety when moving loads through congested areas.

Emergency stop

Allows you to immediately stop the machine.

Anti-crush button

Protect operators and maximize operator safety when moving loads.

Warning horn

Perfect for congested areas, alert pedestrians when moving loads.

Automatic cut-off

Preventing accidental operation of the machine.

Connection

Combi coupling

Creates a secure connection optimizing performance and maneuverability.

Channel coupling

Connect directly to your load to maximize flexibility.

Custom couplings

Need something different? We can design custom couplings to suit your application.

Loads weighing up to 8,800 lbs.

No certification required

Zero emissions

Compact machines for tight spaces

Secure movement of loads

Controlled movement of loads on all-swiveling castors

Suitable for indoor & outdoor use

Unrivaled maneuverability

Your Questions, Answered – FAQs

Can the MasterHandler work in tight spaces?

The compact design of the MasterHandler provides a tight turning circle, making it perfectly suited to working within tight spaces and delivering the precise movement of wheeled loads.

Can the MasterHandler range push and pull?

Yes, the MasterHandler range can push, pull and steer heavy loads weighing up to 8,800 lbs.

What is the maximum speed?

With the Two Speed Selector switch, the ‘Tortoise’ mode enables you to maximize control and operate the machine at a slower speed setting of .75mph. In the faster ‘Hare’ setting, the machine’s speed is 1.86mph.

Machines can be set with custom speed settings where required, with a maximum programmable speed of 3.73mph.

How does the MasterHandler control loads with all-swiveling castors?

With adjustable support legs available to deliver a controlled fixed point, the MasterHandler can safely control swiveling castors. The design of the MasterHandler stops uncontrolled sideways movement and the hydraulic coupling creates an unbreakable connection between the electric tugger and the attached load.

How far can the MasterHandler range travel on one charge?

Battery performance varies from model to model and is influenced by load weight, battery capacity, environmental conditions and usage.

Individual battery performance data can be found on the Technical Specification Sheets for each model.

How do they connect?

A range of coupling options are available across the range that maximize performance, security and safety. Custom coupling solutions can also be designed for unique applications.

Can they work on slopes?

Yes, the MasterHandler range can work safely on slopes.

When it comes to electric tugs, it’s important to understand that for every degree of slope involved, the maximum load capacity of the machine is reduced, just as pushing a car on the level requires less force than on a slope. Therefore, if the weight of the load is already close to the maximum capacity of the machine, a more powerful machine may be needed to move the load on a slope.

We carry out a full evaluation of your application to ensure any machine is suited to your needs.
